Ingress Protection (IP) Testing in Hyderabad

Ingress Protection (IP) Testing in Hyderabad

Product Details:


Product Description

Electronics arelike a grumpy neighbor, Neither can tolerate wet and dirty contaminants (kids)in their enclosures (yards). CDG has developed a set of Ingress Protection (IP)ratings that serves as a unified system of designating electronic enclosure wetand dry contamination resistance. Here we discusses why electronics areparticularly averse to contaminants and how contaminants enter electronic enclosures,as well as discusses IP ratings and examples.Why Electronics are Contaminant Averse,Anycontaminants entering an electronic enclosure or case can cause damage rangingfrom shortened usable life to ultimately rendering the equipment useless. Dustand dirt entering an electronic enclosure can do harm in any one of many ways.Dust is capable of accumulating inside the sockets, ports, and crevices ofelectronics and circuits. If dust builds up excessively, bad things can happen:The dust may build up to form an insulating layer that causes the circuits tooverheat. If the dust or dirt inserts itself between contacting surfaces, poorconductance may occur creating problems for switches, relays, and connectors.In higher voltage applications, the dust and dirt may facilitate arcing betweenline voltage and ground.IEC IP Rating System Overview,Not to be confused withthe highly recognized Internet Protocol, the IEC IP standard measures ingressprotection and has become increasingly popular as consumer electronic devicesbecome more mobile with a focus on ruggedness. The IP designation (or code) isa two digit number, as in IP67, IP68, and IP69K,The first digit of the IP Codeindicates the device s protection level against solid objects.The second digitshows how well liquids are kept from the electronic components and circuitrywithin the enclosure.below shows, solid and liquid protection levelsincrease with higher designated ratings. In IEC IP ratings, solid andliquid protection levels increase with higher designated ratings. 0, Non protected.1, Protected against objects  50 mm. 2, Protectedagainst objects  12.5 mm.3, Protectedagainst objects  2.5 mm.4, Protectedagainst objects  1.0 mm.5, Dust protected.6,Dust tight. The 2  nd digitincludes,0, Non protected.1, Protected against drips.2, Protected against dripsif the housing is bent at an angle of 15.3, Protected against spray water.4, Protectedagainst splash water.4K, Protected against splash water at increased pressure .5,Protected against jet water.6, Protected against strong jet water.6K, Protectedagainst strong jet water at increased pressure.7, Protected against the effectsof temporary submersion in water.8, Protected against the effects of permanentsubmersion in water.9K, Protected against water during high pressure or steamcleaning.An IP rating, then, combines the solid and liquid rating digits,IP67,Dusttight, protected from temporary submersion in water.IP68,Dust tight, protectedfrom continuous submersion in water.IP69K,Dust tight, protected from waterduring high pressure steam cleaning (but not submersible)CIL provides Ingress Protection Testing services in Hyderabad. IP65 Testing, IP67 Testing, IP55 Testing, etc.
